MARUIKEL Customized Commercial Charging Solutions, Professional Solutions and Suggestions
Product Features
▶ Strong compatibility with electric car models.
▶ Multiple intelligent detection and protection functions.
▶ Various charging modes with plug-and-charge, app charging, etc.
▶ Charging methods of automatic full charging, time setting charging, etc.
▶ Voltage ¤t detection and accurate power calculation.
▶ 1.9-inch LCD Screen shows standby,charging and fault status.
▶ Four levels of current setting, equipped with memory function, which defaults to the nearest current level after switching on, without the need for repeated settings.
▶ ETL, FCC, TUVmark, CE certification standards compliant.
Application field
Suitable for home and industrial use.
Suitable for carrying in the car, traveling charging, and emergency charging.
Product Parameters
|
Item |
ZA06-U007KXX-X001 |
ZA06-U09K6XX-X001 |
ZA06-E011KXX-X001 |
ZA06-E022KXX-X001 |
|
Input Voltage |
AC240V±15% |
AC400V±10% |
||
|
Input Frequency |
60Hz±1Hz |
50Hz±1Hz |
||
|
Output Power |
7kW |
9.6kW |
11kW |
22kW |
|
Current |
32A |
40A |
16A(3-phase) |
32A(3-phase) |
|
Current Range |
16A-20A-24A-32A |
16A-24A-32A-40A |
8A-10A-13A-16A |
16A-20A-24A-32A |
|
Communication |
WIFI&Bluetooth |
|||
|
Input Cable Length |
0.5m |
|||
|
Gun Cable Length |
5m/7m/7.5m |
|||
|
Temperature /Humidity |
-30~+40°C/5%~95%RH |
|||
|
Protection |
IP66 |
|||
|
Appearance Size |
Length 420mm;Diameter 80mm |
|||
|
Product Weight |
<5.8KG |
|||
|
Leakage Protection |
A+DC6mA(EU)/CCID20(US) |
|||
